Atdec TH full motion wall mount - Loads up to 77lb - VESA up to 400x400

• Designed for simple installation
• Quick release mechanism for fast TV attachment/removal
• Theft resistant design
• TV tilt adjustment +20°/-5°
• TV horizontal adjustment of -/+5°
• Ball joint allows infinite TV adjustment for any viewing angle up to 40 degree
• Offers a full range of movement via three pivot points
• Designed for simple installation
• Ball joint allows infinite TV adjustment for any viewing angle up to 40°
• Simple tension adjustment
• Smooth Glide technology for effortless articulation or movement
• Maximum reach from wall 21�"(540mm)
• minimum distance from wall 4 ?" (110mm)

The TH-2050-VFM is a cutting-edge full motion mount with incredible versatility. User friendly features are at the heart of its design with Smooth Glide™ thrust-bearing technology to effortlessly move any display up to 77lb. The strong articulated arms allow the screen to be pulled out from the wall and turned to any viewing position. The VESA mounting plate ensures this die cast aluminum mount is compatible with a vast range of displays. It comes pre-assembled with a design that guarantees quick and easy installation. This mount comes pre-assembled for quick and easy installation while the quick attachment/quick release mechanism allows you to install and detach your display in seconds.

• 1 x Articulated Arm
• 1 x VESA Plate
• 1 x Drilling Guide
• 1 x Tightening Tool
• 2 x Extension Plate A
• 2 x Extension Plate B
• 3 x M8 Coach Bolt
• 3 x Concrete Anchor
• 1 x 4mm Allen Key
• 4 x M4 Washer
• 4 x M5 Coach Washer
• 3 x M8 Coach Washer
• 4 x M4 Spacer Bush
• 4 x M5 Spacer Bush
• 4 x M8 Dome Nut
• 4 x M6 Spacer Bush
• 4 x M8 Spacer Bush
• 4 x Star Washer
• 4 x M8 x 16mm Screw
• 4 x M8 x 45mm Screw
• 4 x M6 x 16mm Screw
• 4 x M6 x 30mm Screw
• 4 x M5 x 16mm Screw
• 4 x M5 x 25mm Screw
• 4 x M4 x 16mm Screw
• 4 x M4 x 25mm Screw
