Black Box FlexPoint Gigabit Ethernet Media Converter
Black Box FlexPoint Gigabit Ethernet Media Converter - 1 x RJ-45 , 1 x LC - 1000Base-T, 1000Base-SX - External, Rack-mountable, Wall-mountable
| $957.40 | Retail $1,035.95 |
- Bring fiber to the desktop more conveniently and at a lower cost than installing fiber NICs
- Compact size
- Powered by a universal AC power supply or the optional rackmountable chassis.
- Auto MDI/MDI-X means you never need to worry about what kind of cable to use.
- DIP switches enable you to configure port settings.
By:
Black Box
Manufacturer:
Black Box Corporation
Product ID:
75585
Item:
LMC1009A-R3
UPC Code:
818287072715
Our Part #
43201553
Condition
New
$957.40EA
$1,035.95
$1,035.95
Availability
Only 8 Left In Stock
Product description
Black Box FlexPoint Gigabit Ethernet Media Converter - 1 x RJ-45 , 1 x LC - 1000Base-T, 1000Base-SX - External, Rack-mountable, Wall-mountable
1 x RJ-45 , 1 x LC - 1000Base-T, 1000Base-SX - External, Rack-mountable, Wall-mountable
Specifications
Fiber Mode Supported
Single-mode
Fiber Optic Wavelength
1310 nm
Maximum Distance Supported
6.21 Mile
Network (RJ-45)
Yes
UPC Alternates
818287072715 822088108696
Additional Information
Also be sure to see the rest of the FlexPoint family.
Product works with:
Brand Name
Black Box
Country of origin
United States
Depth
4"
Ethernet Technology
Gigabit Ethernet
Form factor
Wall Mountable
Form factor
Rack-mountable
Form factor
External
Height
1"
Limited Warranty
1 Year
Manufacturer
Black Box Corporation
Manufacturer Part Number
LMC1009A-R3
Manufacturer Website Address
http://www.blackbox.com
Marketing Information
- Sends data up to 10 kilometers (6.2 mi.) on single-mode fiber.
- Manual switches give you the option to control port operation.
- Diagnostic LEDs report power availability and status of the attached devices.
- Hardware available for mounting the converter to a wall or a DIN rail.
- Can also be used in the FlexPoint 14-Slot Power Chassis or the FlexPoint 5-Position Rackmount Kit.
This FlexPoint Modular Media Converter provides plug-and-play conversion from 1000-Mbps UTP to 1000-Mbps fiber. FlexPoint™ Converters from Black Box are versatile and cost-effective standalone converters that you can upgrade to a chassis-based system. They provide the ultimate in flexibility and reliability for your expanding multimedia LAN.
The incredible variety and versatility of this system make it ideal for networks that are subject to constant upgrades and changes. Tailor the system to your requirements. Get the converters you need now and use them individually. Then when your LAN grows mount your converters on the wall in the FlexPoint 5-Position Rackmounting Kit or in the FlexPoint Power Chassis. The chassis holds 14 converters and single or dual AC or DC power supplies.Also be sure to see the rest of the FlexPoint family:
- FlexPoint 10BASE-T to BNC Media Converter (LMC210A)
- FlexPoint 10BASE-T to 10BASE-FL Media Converters (LMC212A-MM-R3 etc.)
- FlexPoint 100BASE-TX to 100BASE-FX Media Converters (LMC213A-MMST-R2 etc.)
- FlexPoint Token Ring UTP to Fiber Media Converter (LTM215A)
- FlexPoint 10/100 Rate Converters (LMC100A-R2 etc.)
- FlexPoint 100-Mbps Fiber to Fiber Converters (LMC252A-ST etc.)
- FlexPoint 1000-Mbps Fiber to Fiber Mode Converters (LMC1001A etc.)
- FlexPoint Fiber-to-Fiber Mode Converters for ATM OC-3 and OC-12 (LMC156A-ST etc.)
- FlexPoint T1/E1 Copper to Fiber Line Drivers (MT660A-MM etc.)
- FlexPoint RS-232 to Fiber Converters (ME660A-MST etc.) Questions? Contact our FREE Tech Support.
Media Type Supported
Optical Fiber
Media Type Supported
Twisted Pair
Network Technology
1000Base-SX
Network Technology
1000Base-T
Number of Network (RJ-45) Ports
1
Power source
Power Supply
Product Condition
New
Product Line
FlexPoint
Product Name
FlexPoint Gigabit Ethernet Media Converter
Product Type
Transceiver/Media Converter
Total Number of Ports
2
Weight (Approximate)
6.40 oz
Width
3"
