StarTech.com MSA Uncoded SFP+ Transceiver Module - 10GBASE-BX - 10 GbE Gigabit Ethernet BiDi Fiber (SMF)
StarTech.com MSA Uncoded SFP+ Transceiver Module - 10GBASE-BX - 10 GbE Gigabit Ethernet BiDi Fiber (SMF) - MSA Uncoded Transceiver - 10GBASE-BX WDM SFP+ (10 Gbps) - 10 Gigabit BiDi Module - 1270nmTx/1330nmRx Single Mode (SMF) - 10km (6.2mi) - LC Connector & DDM - Hot-Swappable / MSA Compliant - Lifetime Warranty
| $136.90 | Retail $527.99 |
- MSA UNCODED SFP+ TRANSCEIVER: 10 Gigabit Ethernet BiDi Fiber Single Strand SFP+ designed, programmed and tested to work with compatible MSA Compliant switches and routers to deliver dependable 10GbE connectivity
- INCREASE BANDWIDTH ON EXISTING INFRASTRUCTURE: This 10 Gigabit Ethernet bi-directional WDM SFP+ transceiver module sends and receives over a single strand of fiber optic cable instead of two.
- TECHNICAL SPECS: 10GBASE-BX | 10Gbps | 10G Bi-Directional Upstream | Single Mode (SMF) | LC Connector | 1270nmTx/1330nmRx | Digital Diagnostic Monitoring (DDM) | Distances up to 10km (6.2mi).
- LIFETIME WARRANTY: Backed by a lifetime warranty on the life of the module itself and not the life of your switch. Our modules won't void your OEM warranty and supported by our Tech Advisors 5/24.
- WORKS WITH MSA COMPLIANT SWITCHES: Works with switch models from Ubiquiti, D-Link, Netgear, Supermicro, TP-Link and more that accept uncoded modules
Manufacturer:
StarTech.com
Product ID:
78885
Item:
SFP10GBBXUST
UPC Code:
065030873406
Our Part #
1DH581
Condition
New
$136.90EA
$527.99
$527.99
Availability
Only 34 Left In Stock
Product description
StarTech.com MSA Uncoded SFP+ Transceiver Module - 10GBASE-BX - 10 GbE Gigabit Ethernet BiDi Fiber (SMF) - MSA Uncoded Transceiver - 10GBASE-BX WDM SFP+ (10 Gbps) - 10 Gigabit BiDi Module - 1270nmTx/1330nmRx Single Mode (SMF) - 10km (6.2mi) - LC Connector & DDM - Hot-Swappable / MSA Compliant - Lifetime Warranty
MSA Uncoded Transceiver - 10GBASE-BX WDM SFP+ (10 Gbps) - 10 Gigabit BiDi Module - 1270nmTx/1330nmRx Single Mode (SMF) - 10km (6.2mi) - LC Connector & DDM - Hot-Swappable / MSA Compliant - Lifetime Warranty
Specifications
Fiber Mode Supported
Single-mode
Interfaces/Ports Details
1 x LC Duplex 10GBase-BX Network
UPC Alternates
065030873406 818214561220 818240336304
Application/Usage
Data Networking
Application/Usage
Optical Network
Compatibility
MSA Compliant
Connector Type
LC
Country of origin
China
Depth
2.3"
Environmental Certification
REACH
Environmental Certification
WEEE
Environmental Certification
RoHS
Environmentally Friendly
Yes
Ethernet Technology
10 Gigabit Ethernet
Form factor
Hot-swappable
Height
0.5"
Limited Warranty
Lifetime
Manufacturer
StarTech.com
Manufacturer Part Number
SFP10GBBXUST
Manufacturer Website Address
http://www.startech.com
Marketing Information
The SFP10GBBXUST is an MSA compliant upstream fiber SFP transceiver which pairs with StarTech.com's SFP10GBBXDST. They are designed programmed and tested to work with 10GBASE-BX compatible MSA switches and routers. The SFP+ transceiver module supports a maximum distance of up to 10 km (6.2 mi) and delivers dependable 10 GbE connectivity over fiber cabling.
Technical Specifications:- Wavelength: 1270nmTx/1330nmRx
- Maximum Data Transfer Rate: 10 Gbps
- Type: Single Mode Fiber
- Connection Type: LC Connector
- Maximum Transfer Distance: 10 km (6.2 mi)
- Power Consumption: Less than 1 Watt
- DDM: Yes
This SFP+ fiber module is hot-swappable making upgrades and replacements seamless by minimizing network disruptions.
StarTech.com SFPsAll StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP Cables providing the convenience and reliability you need to ensure dependable network performance.
Media Type Supported
Optical Fiber
Network Technology
10GBase-BX
Packaged Quantity
1
Product Name
SFP+ Module
Product Type
SFP+
Weight (Approximate)
0.05 lb
