Tripp Lite Duplex Multimode Fiber Patch Cable OM5 LC LC 50/125 100Gb 10M
Tripp Lite Duplex Multimode Fiber Patch Cable OM5 LC LC 50/125 100Gb 10M - Fiber Optic for Network Device - 12.50 GB/s - Patch Cable - 32.81 ft - 2 x LC Male Network - 2 x LC Male Network - 50/125 µm - Lime Green
| $54.84 | Retail $80.00 |
- Rated OM5 to offer a wideband 50/125 multimode fiber solution
- For 40/100 Gb speeds up to 300 meters (at 850 nm)
- Laser-optimized for use with cost-effective VCSEL light sources
- Lime green jacket for easy OM5 identification; 10 m (33 ft.) cable
- Backward compatible with OM3 and OM4 applications
By:
Tripp Lite
Manufacturer:
Tripp Lite by Eaton
Product ID:
79472
Item:
N820-10M-OM5
UPC Code:
037332224255
Our Part #
4AV656
Condition
New
$54.84EA
$80.00
$80.00
Availability
Only 658 Left In Stock
Product description
Tripp Lite Duplex Multimode Fiber Patch Cable OM5 LC LC 50/125 100Gb 10M - Fiber Optic for Network Device - 12.50 GB/s - Patch Cable - 32.81 ft - 2 x LC Male Network - 2 x LC Male Network - 50/125 µm - Lime Green
Fiber Optic for Network Device - 12.50 GB/s - Patch Cable - 32.81 ft - 2 x LC Male Network - 2 x LC Male Network - 50/125 µm - Lime Green
Specifications
Connector on First End Details
2 x LC Network - Male
Connector Type on First End
LC Network - Male
UPC Alternates
037332224255 818243133658
Brand Name
Tripp Lite
Cable Characteristic
Patch Cable
Cable length
32.80 ft
Cable type
Fiber Optic
Color
Lime Green
Connector on First End
2 x LC Male Network
Connector on First End
LC Male Network
Core/Cladding Diameter
50/125 µm
Country of origin
China
Data transfer rate
100 Gbit/s
Device Supported
Network Device
Environmental Certification
RoHS
Environmentally Friendly
Yes
Features
Halogen Free
Fiber Optic Mode
Multi-mode
Limited Warranty
Lifetime
Manufacturer
Tripp Lite by Eaton
Manufacturer Part Number
N820-10M-OM5
Manufacturer Part Number
N82010MOM5
Manufacturer Website Address
http://www.tripplite.com
Marketing Information
Support Higher Bandwidths in Data Networks with OM5 Multimode 50/125 Fiber Patch Cable
As the amount of traffic in data networks grows so does the need for next generation devices and fiber cables to support higher bandwidths. Tripp Lite's OM5 Duplex Multimode 50/125 Fiber Patch Cable is a wideband multimode fiber (WBMMF) solution that supports at least four wavelengths in the 850-950 nm range. This LC to LC multimode fiber optic patch cable is well-suited for 40/100 Gb Ethernet applications up to 300 meters (at 850 nm).
Use with VCSEL Light Sources for a Cost-Effective High-Bandwidth Solution
The N820-10M-OM5 is a laser-optimized multimode fiber (LOMMF) cable designed for use with vertical-cavity surface-emitting lasers (VCSELs) to offer a cost-effective high-bandwidth solution over extended distances in the 850-950 nm wavelength range. It is commonly used in LANs SANs and high-speed parallel interconnects for head-ends central offices and data centers.
Experience Reliable Performance with Premium Construction
Premium materials ensure this multimode fiber cable reliably carries data and voice signals. The cable has duplex male LC connectors on each end and features a low-smoke zero-halogen (LSZH) jacket that limits the amount of toxic smoke emitted in case of combustion making it suitable for poorly ventilated areas. The lime green color of the jacket identifies the cable as OM5 rated. It meets current IEEE 802.3ae and TIA LOMMF standards.
Employ OM5 Cable for Backward Compatibility and Future Proofing
Rated OM5 the N820-10M-OM5 cable is backward compatible with existing OM3- and OM4-rated 50/125 fiber solutions. This LC to LC multimode fiber optic cable can also be used with shortwave wavelength division multiplexing (SWDM) technology to provide transmission over longer distances in the 850-950 nm wavelength range than OM3- and OM4-rated cables. Plus the OM5 cables will be compatible with SWDM solutions in future networks with even higher bandwidths.
Lifetime Warranty
The N820-10M-OM5 is backed by a lifetime limited warranty ensuring reliability and performance.
Product color
Lime Green
Product Model
N820-10M-OM5
Product Name
N820-10M-OM5 Fiber Optic Duplex Patch Network Cable
Product Type
Network Cable
