Tripp Lite PDU Basic 28 5-15/20R L5-20P 5-20P Adapter 1.9kW 15ft Cord 60in
Tripp Lite PDU Basic 28 5-15/20R L5-20P 5-20P Adapter 1.9kW 15ft Cord 60in - Basic - NEMA 5-20P, NEMA L5-20P - 28 x NEMA 5-15/20R - 120 V AC - 0U - Vertical - Rack-mountable
| $201.74 | Retail $273.32 |
- Ideal no-frills PDU for telecom, security, audio/video and other network applications
- 28 NEMA 5-15/20R outlets distribute AC power to connected equipment
- Lighted power switch with protective cover helps prevent accidental shutdowns
- 15 ft. cord with L5-20P input (and 5-20P adapter) connects to AC power source
- 60 in. 0U PDU with included mounting brackets installs in rack or under counter
- 2-year limited warranty
By:
Tripp Lite
Manufacturer:
Tripp Lite by Eaton
Product ID:
81775
Item:
PDUV20-60
UPC Code:
037332256003
Our Part #
8JT037
Condition
New
$201.74EA
$273.32
$273.32
Availability
Only 272 Left In Stock
Product description
Tripp Lite PDU Basic 28 5-15/20R L5-20P 5-20P Adapter 1.9kW 15ft Cord 60in - Basic - NEMA 5-20P, NEMA L5-20P - 28 x NEMA 5-15/20R - 120 V AC - 0U - Vertical - Rack-mountable
Basic - NEMA 5-20P, NEMA L5-20P - 28 x NEMA 5-15/20R - 120 V AC - 0U - Vertical - Rack-mountable
Specifications
Mounting Orientation
Vertical
PDU Type
Basic
Phase
Single Phase
Power Rating (Watt)
2030 W
Receptacle Detail
28 x NEMA 5-15/20R
UPC Alternates
037332256003
Brand Name
Tripp Lite
Country of origin
China
Depth
1.6"
Environmental Certification
RoHS
Environmentally Friendly
Yes
Height
60.5"
Input current
20 A
Input voltage
120 V AC
Limited Warranty
2 Year
Manufacturer
Tripp Lite by Eaton
Manufacturer Part Number
PDUV20-60
Manufacturer Website Address
http://www.tripplite.com
Marketing Information
Single-Phase 120V PDU Distributes Network-Grade Power to Multiple Loads
This basic PDU is an ideal no-frills unit for networking telecom security audio/video and sound reinforcement applications. Recommended for small to mid-sized data centers computer rooms and network closets the PDUV20-60 features 28 NEMA 5-15/20R outlets for connecting equipment. A 15-foot cord with L5-20P input plug (and included 5-20P adapter) connects to your facility's AC power source generator or protected UPS system to distribute power to connected loads.
Up-to-Date Safety Features Protect Your Vital Equipment
A lighted on/off switch is protected by a transparent plastic cover to help prevent an accidental shutdown that could lead to costly downtime. A 20A circuit breaker protects connected components from dangerous overloads.
Versatile Installation Options Give You Plenty of Choices
The 60-inch 0U PDU mounts vertically in an EIA-standard 19-inch rack using the included toolless mounting buttons or the included mounting clips and hardware. You may also use the clips to secure the PDU to a wall counter or other flat secure surface. Bolt-down retention brackets keep power cords organized and your rack free of clutter.
Typical Applications
Deliver network-grade power to high-density equipment in networking telecom security audio/video and sound reinforcement applications
Mount Type
Rack-mountable
Output voltage
100 V AC
Output voltage
127 V AC
Package Contents
- PDUV20-60 28-Outlet PDU
- L5-20P to 5-20P Input Plug Adapter
- Plug Retention Brackets with Installation Hardware
- Rack-Mounting Hardware
- Owner's Manual
Plug/Connector Type
NEMA L5-20P
Plug/Connector Type
NEMA 5-20P
Product Name
PDUV20-60 28-Outlet PDU
Product Type
PDU
Protection Type
Overload Protection
Rack Height
0U
Receptacle Type
NEMA 5-15/20R
Weight (Approximate)
5.39 lb
Width
1.5"
