Tripp Lite PDU 3-Phase Metered 220/230V 22.2kW 32A IEC309 36 C13; 6 C19 0U
Tripp Lite PDU 3-Phase Metered 220/230V 22.2kW 32A IEC309 36 C13; 6 C19 0U - IEC 309 32A Red 3P+N+E - 6 x IEC 60320 C19, 36 x IEC 60320 C13 - 0UVertical Rackmount
| $907.50 | Retail $1,336.60 |
- Metered 22.2kW 3 Phase 380/400V input 220/230V output PDU
- Visual meter reports output amps per bank, total kW and input voltage
- IEC309 32A Red (3P+N+E) 3 phase 380/400V input, 6 ft. / 1.8m line cord
- 42 220/230V outlets (36 C13, 6 C19) with included plug-lock cord retention sleeves
- 0U Vertical Rackmount with Toolless button-mount installation
- TAA Compliant
By:
Tripp Lite
Manufacturer:
Tripp Lite by Eaton
Product ID:
85154
Item:
PDU3XMV6G32
UPC Code:
037332182753
Our Part #
1C4759
Condition
New
$907.50EA
$1,336.60
$1,336.60
Availability
Only 4 Left In Stock
Product description
Tripp Lite PDU 3-Phase Metered 220/230V 22.2kW 32A IEC309 36 C13; 6 C19 0U - IEC 309 32A Red 3P+N+E - 6 x IEC 60320 C19, 36 x IEC 60320 C13 - 0UVertical Rackmount
IEC 309 32A Red 3P+N+E - 6 x IEC 60320 C19, 36 x IEC 60320 C13 - 0UVertical Rackmount
Specifications
Mounting Orientation
Vertical
Power Rating (Watt)
23 kW
Receptacle Detail
6 x IEC 60320 C19
Receptacle Detail
36 x IEC 60320 C13
UPC Alternates
037332182753
Brand Name
Tripp Lite
Circuit Breaker
Yes
Country of origin
Taiwan
Depth
2.5"
Environmental Certification
RoHS
Height
70"
Input current
32 A
Input Voltage Range
380 V AC - 400 V AC
Limited Warranty
2 Year
Manufacturer
Tripp Lite by Eaton
Manufacturer Part Number
PDU3XMV6G32
Manufacturer Website Address
http://www.tripplite.com
Marketing Information
Tripp Lite 3 phase Metered PDU / Power Distribution Units offer real-time local reporting of output current output kW and input voltage via built-in multifunction digital display. Enables visual monitoring of PDU current levels to preserve proper loading balance and prevent circuit overloads as additional equipment is added. Offers reliable rackmount multi-outlet power distribution from any protected UPS generator or mains input power source. High quality design includes rugged all-metal housing and secure rackmount installation with included mounting accessories.
Mount Type
Rack-mountable
Output voltage
240 V AC
Output voltage
200 V AC
Output voltage
220 V AC
Output voltage
230 V AC
Package Contents
- Metered PDU3XMV6G32 42 Outlets PDU
- Cord Retention Sleeves (36 C14 6 C19)
- Spare Installation Buttons (2 9mm / 4 6mm)
- Rack Mounting Brackets
- Owner's Manual
Plug/Connector Type
IEC 60309 32A Red 3P+N+E
Product Line
Metered
Product Name
Metered PDU3XMV6G32 42 Outlets PDU
Product Type
PDU
Protection Type
Overload Protection
Rack Height
0U
Receptacle Type
IEC 60320 C13
Receptacle Type
IEC 60320 C19
Weight (Approximate)
14.29 lb
Width
2.2"
