Tripp Lite PDU Metered 120V 20A 5-15/20R 36 Outlet L5-20P
Tripp Lite PDU Metered 120V 20A 5-15/20R 36 Outlet L5-20P - 72 Inch Height Vertical Rackmount 0URM
| $260.59 | Retail $350.06 |
- Metered single phase 120V 20A 0U 72-in. / 61cm vertical rackmount PDU
- Two-digit current meter reports output current in amps
- Attached 15ft / 4.6m cord with NEMA L5-20P plug and 5-20P adapter
- 36 NEMA 5-15/20R outlets
- Toolless button mount and bolt-down bracket installation hardware included
By:
Tripp Lite
Manufacturer:
Tripp Lite by Eaton
Product ID:
85172
Item:
PDUMV20-72
UPC Code:
037332182838
Our Part #
ZG8013
Condition
New
$260.59EA
$350.06
$350.06
Availability
Currently out of stock
Product description
Tripp Lite PDU Metered 120V 20A 5-15/20R 36 Outlet L5-20P - 72 Inch Height Vertical Rackmount 0URM
72 Inch Height Vertical Rackmount 0URM
Specifications
Mounting Orientation
Vertical
Power Rating (Watt)
2000 W
Receptacle Detail
36 x NEMA 5-15/20R
UPC Alternates
037332182838
Brand Name
Tripp Lite
Certifications & Standards
- Tested to UL60950-1 (USA)
- UL/CSA60950-1 (Canada)
- NOM (Mexico)
- FCC Class A (Emissions)
Cord Length
15 ft
Country of origin
China
Depth
1.3"
Environmental Certification
RoHS
Environmentally Friendly
Yes
Height
72"
Input current
20 A
Input voltage
120 V AC
Limited Warranty
2 Year
Manufacturer
Tripp Lite by Eaton
Manufacturer Part Number
PDUMV20-72
Manufacturer Website Address
http://www.tripplite.com
Marketing Information
Tripp Lite single phase Metered PDU / Power Distribution Units offer real-time local reporting of load level in amps via built-in digital display. Enables visual monitoring of PDU load levels to prevent overloads as additional equipment is added. Offers reliable rackmount multi-outlet power distribution from any protected UPS generator or mains input power source. High quality design includes rugged all-metal housing and secure rackmount installation with included mounting accessories.
Mount Type
Rack-mountable
Package Contents
- PDUMV20-72 Metered Vertical PDU
- 1 x L5-20P to 5-20P Plug Adapter
- Mounting Hardware
- Spare Mounting Buttons
- Instruction Manual with Warranty Information
Plug/Connector Type
NEMA L5-20P
Product Line
Metered
Product Name
PDUMV20-72 Metered Vertical PDU
Product Type
PDU
Protection Type
Overload Protection
Rack Height
0U
Receptacle Type
NEMA 5-15/20R
Weight (Approximate)
5.51 lb
Width
1.8"
