Tripp Lite HDBaseT HDMI Over Cat5e Cat6 Cat6a Extender Receiver, Serial and IR Control 4K x 2K 100m 328ft
Tripp Lite HDBaseT HDMI Over Cat5e Cat6 Cat6a Extender Receiver, Serial and IR Control 4K x 2K 100m 328ft - 1 Output Device - 328 ft Range - 1 x Network (RJ-45) - 1 x HDMI Out - Serial Port - 4K - 3840 x 2160 - Twisted Pair - Category 6a - Wall Mountable, Rack-mountable, Pole-mountable"
| $117.52 | Retail $345.60 |
- Extends a 3840 x 2160 (4K x 2K) signal up to 328 ft. (100 m)
- Extends a 1080p @ 60 Hz signal up to 328 ft. (100 m)
- Supports 7.1-channel surround sound, DTS-HD and Dolby TrueHD
- Mounts easily to wall, rack or pole
- Plug and play-no software or drivers to install
By:
Tripp Lite
Manufacturer:
Tripp Lite by Eaton
Product ID:
85607
Item:
BHDBT-R-SI-LR
UPC Code:
037332187024
Our Part #
1U5244
Condition
New
$117.52EA
$345.60
$345.60
Availability
Only 111 Left In Stock
Product description
Tripp Lite HDBaseT HDMI Over Cat5e Cat6 Cat6a Extender Receiver, Serial and IR Control 4K x 2K 100m 328ft - 1 Output Device - 328 ft Range - 1 x Network (RJ-45) - 1 x HDMI Out - Serial Port - 4K - 3840 x 2160 - Twisted Pair - Category 6a - Wall Mountable, Rack-mountable, Pole-mountable"
1 Output Device - 328 ft Range - 1 x Network (RJ-45) - 1 x HDMI Out - Serial Port - 4K - 3840 x 2160 - Twisted Pair - Category 6a - Wall Mountable, Rack-mountable, Pole-mountable"
Specifications
Receiver Depth
2.50"
Receiver Height
1.10"
Receiver Weight (Approximate)
8.80 oz
Receiver Width
4.50"
UPC Alternates
037332187024
Brand Name
Tripp Lite
Connectivity technology
Wired
Country of origin
Taiwan
Environmental Certification
REACH
Environmental Certification
RoHS
Environmentally Friendly
Yes
Form factor
Rack-mountable
Form factor
Wall Mountable
Form factor
Pole-mountable
Graphics Modes
4K
Limited Warranty
1 Year
Manufacturer
Tripp Lite by Eaton
Manufacturer Part Number
BHDBT-R-SI-LR
Manufacturer Website Address
http://www.tripplite.com
Marketing Information
The BHDBT-R-SI-LR HDBaseT Extender Receiver works in tandem with the Tripp Lite BHDBT-Series matrix transmitter in your HDBaseT installation to extend uncompressed HDMI video and audio RS-232 serial and IR remote control signals.
Using a single Cat5e/6/6a cable the BHDBT-R-SI-LR can extend a 1920 x 1080(1080p) signal at 60 Hz or an Ultra High Definition(UHD) 3840 x 2160(4K x 2K) video signal up to 328 feet(100 m). To further extend and expand your installation you can insert up to five BHDBT-TR-SI-LR Extender Transceivers between the receiver and transmitter for a total range up to 2000 feet(610 m) with a monitor connected to each transceiver.
You can control RS-232 serial devices such as touchscreen displays or scanners at baud rates up to 115 Kbps. The 2-way IR Remote Control feature(@ 39 KHz) lets you also control your Blu-ray player using its remote when at the remote monitor and vice versa. The monitor connects to the rear locking HDMI port(ideal for use with Tripp Lite's P569-006-LOCK High-Speed HDMI cables with locking connectors) that prevents the cable from coming loose or undone ensuring an intact signal.
The BHDBT-R-SI-LR supports 7.1-channel surround sound DTS-HD and Dolby TrueHD audio as well as 3D video EDID and HDCP. Included mounting hardware lets you attach the receiver to a wall rack or pole. Sets up quickly with no software to download or install.
Using a single Cat5e/6/6a cable the BHDBT-R-SI-LR can extend a 1920 x 1080(1080p) signal at 60 Hz or an Ultra High Definition(UHD) 3840 x 2160(4K x 2K) video signal up to 328 feet(100 m). To further extend and expand your installation you can insert up to five BHDBT-TR-SI-LR Extender Transceivers between the receiver and transmitter for a total range up to 2000 feet(610 m) with a monitor connected to each transceiver.
You can control RS-232 serial devices such as touchscreen displays or scanners at baud rates up to 115 Kbps. The 2-way IR Remote Control feature(@ 39 KHz) lets you also control your Blu-ray player using its remote when at the remote monitor and vice versa. The monitor connects to the rear locking HDMI port(ideal for use with Tripp Lite's P569-006-LOCK High-Speed HDMI cables with locking connectors) that prevents the cable from coming loose or undone ensuring an intact signal.
The BHDBT-R-SI-LR supports 7.1-channel surround sound DTS-HD and Dolby TrueHD audio as well as 3D video EDID and HDCP. Included mounting hardware lets you attach the receiver to a wall rack or pole. Sets up quickly with no software to download or install.
Maximum Operating Distance
328 ft
Maximum Video Resolution
3840 x 2160
Media Type Supported
Twisted Pair
Number of Network (RJ-45) Ports
1
Package Contents
- BHDBT-R-SI-LR HDBaseT HDMI over Cat5e/6/6a Extender Receiver
- IR-IN Cable
- IR-OUT Cable
- 3.5 mm Male to DB9 Female Adapter Cable
- 3.5 mm Male to DB9 Male Adapter Cable
- External Power Supply (Input: 100-240V 50/60 Hz 0.5A; Output: 5V 3A)
- Mounting Hardware
- Owner's Manual
Product color
Black
Product Name
BHDBT-R-SI-LR HDBaseT HDMI over Cat5e/6/6a Extender Receiver
Product Type
Video Extender Receiver
Twisted Pair Cable Standard
Category 6a
