Taoglas Barracuda OMB.6912.03F21 4G/3G/2G 4.5dBi Omnidirectional Outdoor Antenna
Taoglas Barracuda OMB.6912.03F21 4G/3G/2G 4.5dBi Omnidirectional Outdoor Antenna - 698 MHz to 803 MHz, 824 MHz to 894 MHz, 880 MHz to 960 MHz, 1710 MHz to 1880 MHz, 1850 MHz to 1990 MHz, 1920 MHz to 2170 MHz, 2490 MHz to 2700 MHz - 5.6 dBi - Indoor, Outdoor, Cellular NetworkPole/Wall - Omni-directional - N-Type Connector
| $105.41 |
- Omni-Directional Radiation Pattern
- 4.5 dBi Peak gain
- Covers all 4G/3G/2G bands
- Robust design for all weather operation
- IP65 waterproof
- 320mm in length, 150g weight
- N type Female connector
- Mounting bracket Included
- RoHS compliant
Manufacturer:
Taoglas
Product ID:
87816
Item:
OMB.6912.03F21
Our Part #
3AM640
Condition
New
$105.41EA
Availability
Only 54 Left In Stock
You may be also interested
Product description
Taoglas Barracuda OMB.6912.03F21 4G/3G/2G 4.5dBi Omnidirectional Outdoor Antenna - 698 MHz to 803 MHz, 824 MHz to 894 MHz, 880 MHz to 960 MHz, 1710 MHz to 1880 MHz, 1850 MHz to 1990 MHz, 1920 MHz to 2170 MHz, 2490 MHz to 2700 MHz - 5.6 dBi - Indoor, Outdoor, Cellular NetworkPole/Wall - Omni-directional - N-Type Connector
698 MHz to 803 MHz, 824 MHz to 894 MHz, 880 MHz to 960 MHz, 1710 MHz to 1880 MHz, 1850 MHz to 1990 MHz, 1920 MHz to 2170 MHz, 2490 MHz to 2700 MHz - 5.6 dBi - Indoor, Outdoor, Cellular NetworkPole/Wall - Omni-directional - N-Type Connector
Specifications
Antenna Gain
5.6 dBi
Directivity
Omni-directional
Operating Frequency Range
1710 MHz to 1880 MHz
Operating Frequency Range
1920 MHz to 2170 MHz
Operating Frequency Range
698 MHz to 803 MHz
Operating Frequency Range
2490 MHz to 2700 MHz
Operating Frequency Range
880 MHz to 960 MHz
Operating Frequency Range
1850 MHz to 1990 MHz
Operating Frequency Range
824 MHz to 894 MHz
Application/Usage
Indoor
Application/Usage
Cellular Network
Application/Usage
Outdoor
Connector Type
N-Type
Diameter
1.02"
Environmental Certification
RoHS
Environmentally Friendly
Yes
Form factor
Pole/Wall
Height
12.60"
Manufacturer
Taoglas
Manufacturer Part Number
OMB.6912.03F21
Manufacturer Website Address
http://www.taoglas.com
Marketing Information
The OMB.6912.03F21 is a 4G fiberglass omnidirectional outdoor antenna operating in the worldwide 4G 698-960 and 1710-2700MHz bands and has 4.5 dBi maximum gain. The collinear dipole array antenna is designed especially for outdoor applications connecting via 4G routers and modules. Its compact dimensions of 320mm in length and 70mm diameter allow it to be mounted conveniently and unobtrusively in any location compared to traditional fiberglass omni antennas which are twice the size.
The omnidirectional antenna radiates uniformly in the azimuth providing long distance coverage thus minimizing the number of nodes needed for a radio network.
The UV resistant fiberglass housing enables this OMB series antenna to be used in harsh weather environments making it more robust and safer than traditional whip antennas. The main band of operation is between 698MHz to 2170MHz; however it can also be used for shorter range 2600MHz applications.
The antenna can be mounted on a wall via the convenient pre-installed mounting bracket or on a pole with the additional supplied U-bolt. An industry standard N-type Female connector is used. The connector can be customized upon request subject to MOQ. Contact your regional Taoglas sales office for details.
Package Contents
- Barracuda OMB.6912.03F21 4G/3G/2G 4.5dBi Omnidirectional Outdoor Antenna
- Mounting Bracket
Product Name
Barracuda OMB.6912.03F21 4G/3G/2G 4.5dBi Omnidirectional Outdoor Antenna
Product Type
Antenna
Weight (Approximate)
5.29 oz
