Netgear XSM4556 Ethernet Switch
Netgear XSM4556 Ethernet Switch - 48 Ports - Manageable - 3 Layer Supported - Modular - Optical Fiber - 1U High - Rack-mountable, Rail-mountable - Lifetime Limited Warranty
| $18,267.00 | Retail $24,756.14 |
- Features 48 networking ports to meet the requirements of the most demanding workgroups
- Supports optical fiber cable to span longer distances and provided high data transmission rates between servers and network components
- Can work as layer 3 routing for scalable network design
- Management capability provides control over setup and configuration of your network
- Built-in power supply to ensure all components are being supplied with accurate voltage
By:
Netgear
Manufacturer:
Netgear, Inc
Product ID:
89418
Item:
XSM4556-100NAS
UPC Code:
606449145700
Our Part #
6LR089
Condition
New
$18,267.00EA
$24,756.14
$24,756.14
Availability
Only 2 Left In Stock
Product description
Netgear XSM4556 Ethernet Switch - 48 Ports - Manageable - 3 Layer Supported - Modular - Optical Fiber - 1U High - Rack-mountable, Rail-mountable - Lifetime Limited Warranty
48 Ports - Manageable - 3 Layer Supported - Modular - Optical Fiber - 1U High - Rack-mountable, Rail-mountable - Lifetime Limited Warranty
Specifications
Compatible Rack Unit
1U
Number of Total Expansion Slots
56
Total Number of Network Ports
48
UPC Alternates
606449145700
Brand Name
Netgear
Country of origin
China
Depth
20"
Environmental Certification
RoHS
Environmental Certification
REACH
Environmental Certification
WEEE
Environmental Certification
ErP
Ethernet Technology
100 Gigabit Ethernet
Ethernet Technology
25 Gigabit Ethernet
Expansion Slot Type
SFP28
Expansion Slot Type
QSFP28
Form factor
Rack-mountable
Form factor
Rail-mountable
Height
1.7"
Layer Supported
3
Limited Warranty
Lifetime
Manageable
Yes
Manufacturer
Netgear Inc
Manufacturer Part Number
XSM4556-100NAS
Manufacturer Website Address
http://www.netgear.com
Marketing Information
The trend of moving matrix switching into the Ethernet network is accelerating and AV over IP already delivers capabilities far beyond that of a traditional matrix switch. Historically it has been simple to design AV over IP systems of up to 96 I/Os using a single switch and Layer-2 Multicast IGMP. However larger installations required data center-class 100G Ethernet switches with more complex Layer-3 multicast routing techniques adding complexity and cost to the Ethernet infrastructure. As networked AV systems become ever larger a new class of switches has come to market. They combine the configurability of a matrix switch with the power and scalability of Ethernet to support hundreds of AV over IP endpoints at a price point dramatically cheaper than comparable matrix switches. Introducing two new 100GE enabled switches for ProAV the M4500 series. Removing the need for Layer-3 PIM routing these new switches offer IGMP Plus and greatly simplify system architectures with the same well-known Layer-2 techniques across the entire AV over IP network. Installers opting to use M4500 switches in their installation will find that it is already preconfigured out of the box.
Highlights
A 10G to 100G solution
Highlights
A 10G to 100G solution
- The M4500-32C offers 32-port QSFP28 preconfigured for 100G and can support 40G QSFP+ and 50G QSFP28 optics or DAC cables
- The M4500-48XF8C offers 48-port SFP28 preconfigured for 10G with 8-port 100G QSFP28 uplinks and the SFP28 ports can support 10G and 25G
- Installers opting to use M4500 switches in their installation will find that it is already preconfigured out of the box
- True AV and multicast Zero Touch network configuration: Connect AV-over-IP encoders and decoders and power on the switch. It just works!
- IGMP Plus multicast allows for scalable Pro AV installations at Layer 2 without the PIM (Protocol Independent Multicast) complexity
- IGMP Plus is default on VLAN 1 out of the box and can be configured on another VLAN for automatic IGMP across M4500 and M4300 switches on that VLAN
- Meet the requirements of high performance high availability fast scale out low latency performance and continuous serviceability in sensible applications
- The M4500 switches offer 1+1 power and 4+2 fan redundancy an x86 Intel Atom® Processor C3558 with 8GB DDR3/ECC RAM and 128GB SSD storage
- The M4500 switches come with an industry standard command line interface (CLI) SSH SNMP sFlow and MLAG
- An out of band 1 Gigabit Ethernet port facilitates management with simplified macro-commands for AV-over-IP configuration
- NETGEAR M4500 series is covered under NETGEAR ProSAFE Limited Lifetime Hardware Warranty
- 90 days of Technical Support via phone and email Lifetime Technical Support through online chat and Lifetime Next Business Day hardware replacement
Media Type Supported
Optical Fiber
Network Technology
25GBase-X
Network Technology
1000Base-X
Package Contents
- XSM4556 Ethernet Switch
- 2 x Power Supplies and Six Fan Trays Already Installed
- Power Cord(s)
- Console Cable with One DB9 Female Connector and One RJ-45 Serial Connector
- 2 x Mounting Ears and Screws For Rack Mounting (Front)
- 1 x Set of Rail Kits For Rack Mounting (Back)
Port/Expansion Slot Details
48 x 25 Gigabit Ethernet Expansion Slot
Port/Expansion Slot Details
8 x 100 Gigabit Ethernet Uplink
Power source
Power Supply
Product Model
XSM4556
Product Name
XSM4556 Ethernet Switch
Product Series
M4500
Product Type
Ethernet Switch
Weight (Approximate)
21.43 lb
Width
17.3"
