Axiom 40Gbs Dual Port QSFP+ PCIe 3.0 x8 NIC Card for Dell - 540-BBRN
Axiom 40Gbs Dual Port QSFP+ PCIe 3.0 x8 NIC Card for Dell - 540-BBRN - PCI Express 3.0 x8 - 5 GB/s Data Transfer Rate - Intel XL710AM2 - 2 Port(s) - Optical Fiber - 40GBase-X - QSFP+ - Plug-in Card
| $951.04 |
- The 40Gigabit Ethernet card will provide high-performance Ethernet for servers and high-end appliances while minimizing the usage of both power and CPU cycles
- This 8000 MB/s bandwidth PCI Express 3.0 x8 adapter ensures easy connectivity and plug-in form-factor for affordable and reliable Ethernet network
- For high bandwidth connectivity, add this efficient dual port 40gigabit ethernet card to your server or workstation
- Supports optical fiber cable to span longer distances and provides data transmission rates par excellence between servers and network components
- With the 40GBase-X technology get up to 40Gbps data transfer rate over the supported network cable
By:
Axiom
Manufacturer:
Axiom Memory Solutions
Product ID:
90888
Item:
540-BBRN-AX
UPC Code:
840177848803
Our Part #
43201404
Condition
New
$951.04EA
Availability
Only 15 Left In Stock
Product description
Axiom 40Gbs Dual Port QSFP+ PCIe 3.0 x8 NIC Card for Dell - 540-BBRN - PCI Express 3.0 x8 - 5 GB/s Data Transfer Rate - Intel XL710AM2 - 2 Port(s) - Optical Fiber - 40GBase-X - QSFP+ - Plug-in Card
PCI Express 3.0 x8 - 5 GB/s Data Transfer Rate - Intel XL710AM2 - 2 Port(s) - Optical Fiber - 40GBase-X - QSFP+ - Plug-in Card
Specifications
Chipset Model
XL710AM2
UPC Alternates
840177848803
Brand Name
Axiom
Chipset Manufacturer
Intel
Data transfer rate
5 GB/s
Depth
2.7"
Device Supported
NAS Storage Device/Server
Expansion Slot Type
QSFP+
Form factor
Plug-in Card
Height
6.5"
Host interface
PCI Express 3.0 x8
Limited Warranty
3 Year
Manufacturer
Axiom Memory Solutions
Manufacturer Part Number
540-BBRN-AX
Manufacturer Website Address
http://www.axiommemory.com
Marketing Information
Features
The Axiom QSFP+ PCIe 3.0 x8 40Gbs Fiber Network Adapter is designed for Servers and high-end appliances. They offer simple integration into any PCI Express X8 to 40 Gigabit Networks. Based on Intel XL710AM Ethernet controller with two fully integrated Gigabit Ethernet Media Access Control (MAC) and XLPPI Interfaces the Axiom QSFP+ NIC cards are the ideal solution for implementing multiple network segments mission-critical high-powered networking applications and environments within high performance servers.
Key Features:
- Network Virtualization offloads for VXLAN and NVGRE
- Unified Networking Providing a single wire for LAN and storage: NAS (SMB NFS) and SAN (iSCSIFCoE)
- Virtual Bridging Support - VEPA/802.1QbgBPE/802.1Qbh
- Physical Functions - Up to 8 per port
- Support for 128 Virtual Device Queues (VMDq) per port
- Hardware Queue Pairs - Up to 1.5K (non-RDMA); up to 256K (RDMA)
- Virtualization - Alleviating hypervisor I/O bottlenecks by providing flow separation for Virtual Machines
- Includes Full Height and Half Height Mounting Brackets
Media Type Supported
Optical Fiber
Network Technology
40GBase-X
Package Contents
- 40Gbs Dual Port QSFP+ PCIe 3.0 x8 NIC Card for Dell - 540-BBRN
- Full Height Mounting Brackets
- Half Height Mounting Brackets
Product Name
40Gbs Dual Port QSFP+ PCIe 3.0 x8 NIC Card for Dell - 540-BBRN
Product Type
40Gigabit Ethernet Card
Total Number of Ports
2
Weight (Approximate)
4.96 oz
Width
0.5"
