Elo 1590L 15" Open-frame LCD Touchscreen Monitor - 4:3 - 16 ms
Elo 1590L 15" Open-frame LCD Touchscreen Monitor - 4:3 - 16 ms - 15" Class - IntelliTouch Surface Wave - 1024 x 768 - XGA - Thin Film Transistor (TFT) - 16.2 Million Colors - 700:1 - 300 Nit, 270 Nit - LED Backlight - HDMI - USB - VGA - DisplayPort - Black - T�V, RoHS, China RoHS, WEEE - 3 Year
| $633.19 |
- Explore a world loaded with potentially vivid entertainment outcomes with the Elo Open-frame LCD Touchscreen Monitor
- LED backlight technology provides for industry-leading low power consumption and less hazardous materials
- The 700:1 contrast ratio produces enhanced sharpness and shading accuracy in each picture
- Furnishes captivating visuals with about 300 Nit brightness levels
- The IntelliTouch Surface Wave touchscreens comprise of a glass overlay with the transmitting and accepting piezoelectric transducers for the X and Y-axis
- VESA mount compatibility allows you to mount the touch screen on a wall or with a stand depending on your specific needs
By:
Elo
Manufacturer:
Elo Touch Solutions, Inc
Product ID:
95922
Item:
E326738
UPC Code:
037321584834
Our Part #
3GU996
Condition
New
$633.19EA
Availability
Only 10 Left In Stock
You may be also interested
Product description
Elo 1590L 15" Open-frame LCD Touchscreen Monitor - 4:3 - 16 ms - 15" Class - IntelliTouch Surface Wave - 1024 x 768 - XGA - Thin Film Transistor (TFT) - 16.2 Million Colors - 700:1 - 300 Nit, 270 Nit - LED Backlight - HDMI - USB - VGA - DisplayPort - Black - T�V, RoHS, China RoHS, WEEE - 3 Year
15" Class - IntelliTouch Surface Wave - 1024 x 768 - XGA - Thin Film Transistor (TFT) - 16.2 Million Colors - 700:1 - 300 Nit, 270 Nit - LED Backlight - HDMI - USB - VGA - DisplayPort - Black - T�V, RoHS, China RoHS, WEEE - 3 Year
Specifications
Curved Screen
No
DisplayPort Version
1.1a
HDMI Version
1.3
Panel Technology
Thin Film Transistor (TFT)
Touchscreen Type
IntelliTouch Surface Wave
UPC Alternates
037321584834 657379220449 686727755494 815335025815
UPC Alternates
037321584834 657379220449 686727755494 815335025815 818213929465 818214084156
Vertical Viewing Angle
150°
VESA Mount Standard
100 x 100
Aspect ratio
4:3
Backlight Technology
LED
Brand Name
Elo
Brightness
300 Nit
Brightness
270 Nit
Certifications & Standards
Color Supported
16.2 Million Colors
Contrast Ratio
700:1
Depth
1.7"
Energy Consumption per Year
21 kWh
Environmental Certification
T�V
Environmental Certification
RoHS
Environmental Certification
China RoHS
Environmental Certification
WEEE
Environmentally Friendly
Yes
Features
Anti-glare
Features
On-screen Display (OSD)
Height
10.4"
Horizontal Viewing Angle
160°
Limited Warranty
3 Year
Manufacturer
Elo Touch Solutions Inc
Manufacturer Part Number
E326738
Manufacturer Website Address
http://www.elotouch.com
Marketing Information
The Elo 1590L 15-inch open-frame LCD touch display features a slim design and narrow outside dimensions due to the state-of-the-art energy-saving LED backlight using less electricity to operate and generating less heat. This compact touch display is designed for touch with proven Elo expertise and reliability built in. The 1590L provides stable drift-free operation with outstanding image clarity and light transmission-for accurate touch responses and vivid images. Instantly grabbing and holding users' attention the 15-inch open frame is perfect for kiosks casino and amusement retail self-service and industrial automation environments.
Easily integrated.
Easily integrated.
The touchscreen is sealed against dirt dust and liquids which simplifies integration into the final enclosure. Projected capacitive (PCAP) units can be sealed into a solution and obtain an IP65 rating on the front side of the unit. With the design and tooling being controlled by Elo long-lasting product availability can be expected.
Touch ready.
The 1590L is available with a choice of industry-leading single-touch or multi-touch technologies. The seamless zero-bezel 15-inch multi-touch display is available with our latest TouchPro™ PCAP two-glass solution (2GS) technology that delivers both a 10-touch tablet-like experience along with two-touch thru-glass functionality-both modes support single or dual latex gloves as well as cloth gloves. Standard bezel single-touch display options include AccuTouch® five-wire resistive IntelliTouch® SAW or SecureTouch® anti-vandal SAW.
Commercial-grade.
The Elo open frame touchscreen display delivers the quality and reliability Elo is known for and is backed by our three-year standard warranty. We design build and are responsible for the complete solution with touch integrated from the start. Using our touchscreens combined with our software and drivers everything is designed to work together and is tested as part of our life-testing processes. All our products go through rigorous reliability testing (over 20 tests) to deliver 50000 MTBF.
Other features.
- Projected capacitive (PCAP) two glass solution (2GS) offers pristine optical clarity and touch durability that passes UL-60950 & IK-07 impact testing
- Display Port and VGA video interfaces
- 10-touch TouchPro projected capacitive (PCAP) with two-touch thru-glass capabilities
Maximum resolution
1024 x 768
Mean time between failures (MTBF)
5.7 Year
Mount Type
Rack-mountable
Mount Type
Front Mount
Off-Mode Power Consumption
500 mW
Operating Power Consumption
14 W
Package Contents
- 1590L 15" Open Frame Touchscreen (Rev B)
- HDMI cable
- VGA Cable
- RJ45 OSD Remote
- Touch USB Cable
- User Manual CD
- Quick Install Guide
- "L" (Side Mount) Brackets and w/Screws
- EEI Label
- Japan Class-B TM info sheet
Packaged Quantity
1
Product color
Black
Product Model
1590L
Product Name
1590L 15" Open Frame Touchscreen (Rev B)
Product Type
Open-frame LCD Touchscreen Monitor
Response time
16 ms
Screen Mode
XGA
Standby Power Consumption
1.50 W
USB Standard
USB 2.0
Viewable Screen Size
15"
Weight (Approximate)
6.40 lb
Width
13.2"
