Tripp Lite PDU Monitored 208/230V 20A 18 C13;2 C19 C20/L6-20P LX Interface
Tripp Lite PDU Monitored 208/230V 20A 18 C13;2 C19 C20/L6-20P LX Interface - Monitored - NEMA L6-20P, IEC 60320 C20 - 2 x IEC 60320 C19, 18 x IEC 60320 C13 - 230 V AC - 0U - Vertical - Rack Mount - Rack-mountable - TAA Compliant
| $451.09 | Retail $666.44 |
- 3.3/3.7kW 208/230V single-phase monitored 90cm 0U PDU
- 20 outlets-18 C13, 2 C19-with plug-lock insert sleeves
- Built-in Java-free LX Platform interface for remote access 24/7
- Digital ammeter for on-site load monitoring in real time
- C20 inlet input with detachable 10 ft. NEMA L6-20P power cord
By:
Tripp Lite
Manufacturer:
Tripp Lite by Eaton
Product ID:
96554
Item:
PDUMNV20HV2LX
UPC Code:
037332205346
Our Part #
2KL111
Condition
New
$451.09EA
$666.44
$666.44
Availability
Only 75 Left In Stock
Product description
Tripp Lite PDU Monitored 208/230V 20A 18 C13;2 C19 C20/L6-20P LX Interface - Monitored - NEMA L6-20P, IEC 60320 C20 - 2 x IEC 60320 C19, 18 x IEC 60320 C13 - 230 V AC - 0U - Vertical - Rack Mount - Rack-mountable - TAA Compliant
Monitored - NEMA L6-20P, IEC 60320 C20 - 2 x IEC 60320 C19, 18 x IEC 60320 C13 - 230 V AC - 0U - Vertical - Rack Mount - Rack-mountable - TAA Compliant
Specifications
Mounting Orientation
Vertical
PDU Type
Monitored
Phase
Single Phase
Power Rating (Watt)
3700 W
Receptacle Detail
18 x IEC 60320 C13
Receptacle Detail
2 x IEC 60320 C19
UPC Alternates
037332205346
Brand Name
Tripp Lite
Country of origin
Taiwan
Depth
1.9"
Environmental Certification
RoHS
Environmentally Friendly
Yes
Height
35.5"
Input current
20 A
Input voltage
230 V AC
Limited Warranty
2 Year
Management
Protocols:
- IPv4
- IPv6
- HTTP
- HTTPS
- SMTP
- SNMPv1
- SNMPv2
- SNMPv3
- telnet
- SSH
- FTP
- DHCP
- NTP
Manufacturer
Tripp Lite by Eaton
Manufacturer Part Number
PDUMNV20HV2LX
Manufacturer Website Address
http://www.tripplite.com
Marketing Information
The PDUMNV20HV2LX 3.3/3.7kW Single-Phase Monitored PDU provides real-time remote monitoring of voltage frequency and load levels via built-in network connection. By reducing the frequency of on-site visits these advanced remote capabilities can save you money and reduce downtime.
Recommended for your IT or industrial application the 0U PDU features 20 outlets (18 C13 and 2 C19) with included plug-lock insert sleeves to prevent cables from becoming accidentally disconnected. The C20 inlet is compatible with a wide variety of user-supplied power cords for connecting to an AC source generator or protected UPS. A detachable 10-foot cord with NEMA L6-20P plug is included.
The built-in Java-free HTML5-based LX Platform network interface enables full remote access for PDU status monitoring and email notifications via secure web browser SNMP telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported include IPv4 IPv6 HTTP HTTPS SMTP SNMPv1 SNMPv2 SNMPv3 telnet SSH FTP DHCP and NTP.
A digital ammeter allows you to monitor the total connected load in real time to ensure it remains well below maximum capacity with no danger of overload. The PDU mounts in 0U of space in EIA-standard 19-inch racks using the included toolless mounting buttons or the included rack-mounting brackets.
Recommended for your IT or industrial application the 0U PDU features 20 outlets (18 C13 and 2 C19) with included plug-lock insert sleeves to prevent cables from becoming accidentally disconnected. The C20 inlet is compatible with a wide variety of user-supplied power cords for connecting to an AC source generator or protected UPS. A detachable 10-foot cord with NEMA L6-20P plug is included.
The built-in Java-free HTML5-based LX Platform network interface enables full remote access for PDU status monitoring and email notifications via secure web browser SNMP telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported include IPv4 IPv6 HTTP HTTPS SMTP SNMPv1 SNMPv2 SNMPv3 telnet SSH FTP DHCP and NTP.
A digital ammeter allows you to monitor the total connected load in real time to ensure it remains well below maximum capacity with no danger of overload. The PDU mounts in 0U of space in EIA-standard 19-inch racks using the included toolless mounting buttons or the included rack-mounting brackets.
Mount Type
Rack-mountable
Output voltage
208 V AC
Package Contents
- PDUMNV20HV2LX 20-Outlet PDU
- Built-in LX Platform Interface
- Detachable NEMA L6-20P to C19 Power Cord 10 ft.
- Configuration Cable
- 20 x Plug-lock Inserts
- Rack-mounting hardware
- Mounting Bracket Accessory
- Owner's Manual
Plug/Connector Type
IEC 60320 C20
Plug/Connector Type
NEMA L6-20P
Product Name
PDUMNV20HV2LX 20-Outlet PDU
Product Type
PDU
Rack Height
0U
Receptacle Type
IEC 60320 C13
Receptacle Type
IEC 60320 C19
Weight (Approximate)
6.50 lb
Width
2.2"
