Tripp Lite PDU 3-Phase Basic 120V 5.7kW 42 5-15/20R 208V L21-20P 70in 0URM
Tripp Lite PDU 3-Phase Basic 120V 5.7kW 42 5-15/20R 208V L21-20P 70in 0URM - Basic - NEMA L21-20P - 42 x NEMA 5-15/20R - 230 V AC - 0U - Vertical/Toolless - Rack-mountable - TAA Compliant
| $472.68 | Retail $696.38 |
- PDU allows power to be more efficiently distributed and controlled
- Basic PDU deliver power to wiring closets, server rooms & equipment racks in a cost-effective way
By:
Tripp Lite
Manufacturer:
Tripp Lite by Eaton
Product ID:
99646
Item:
PDU3V6L2120LV
UPC Code:
037332255709
Our Part #
8JU665
Condition
New
$472.68EA
$696.38
$696.38
Availability
Only 74 Left In Stock
You may be also interested
Product description
Tripp Lite PDU 3-Phase Basic 120V 5.7kW 42 5-15/20R 208V L21-20P 70in 0URM - Basic - NEMA L21-20P - 42 x NEMA 5-15/20R - 230 V AC - 0U - Vertical/Toolless - Rack-mountable - TAA Compliant
Basic - NEMA L21-20P - 42 x NEMA 5-15/20R - 230 V AC - 0U - Vertical/Toolless - Rack-mountable - TAA Compliant
Specifications
Locking Receptacles
Cord Retention Bracket
Mounting Orientation
Vertical/Toolless
PDU Type
Basic
Phase
Three Phase
Power Rating (Watt)
5700 W
Receptacle Detail
42 x NEMA 5-15/20R
UPC Alternates
037332255709
Brand Name
Tripp Lite
Country of origin
Taiwan
Depth
1.7"
Environmental Certification
RoHS
Environmentally Friendly
Yes
Height
70"
Input current
16 A
Input voltage
230 V AC
Limited Warranty
2 Year
Manufacturer
Tripp Lite by Eaton
Manufacturer Part Number
PDU3V6L2120LV
Manufacturer Website Address
http://www.tripplite.com
Marketing Information
3-Phase 120V PDU Distributes Network-Grade Power to Multiple Loads
This basic PDU is an ideal no-frills unit for networking telecom security audio/video and sound reinforcement applications. Recommended for small to mid-sized data centers computer rooms and network closets the PDU3V6L2120LV features 42 NEMA 5-15/20R outlets in three single-phase output load banks for connecting equipment. A six-foot (1.8-meter) cord with NEMA L21-20P 3-phase input plug connects to your facility's AC power source generator or protected UPS system to distribute power to connected loads.
Easy to Install Vertically in an EIA-Standard 19 in. Rack
The 70-inch 0U PDU's all-metal housing mounts vertically using the pre-installed toolless mounting buttons or the included brackets. Spare buttons are also included. Use the included PDUMVROTATEBRKT kit to install the PDU with outlets facing the rear for better airflow or equipment access. Cable retention brackets keep power cords organized and your rack free of clutter. The PDU's switchless design helps prevent an accidental shutdown which could lead to costly downtime.
TAA-Compliant for GSA Schedule Purchases
The PDU3V6L2120LV is compliant with the Federal Trade Agreements Act (TAA) which makes it eligible for GSA (General Services Administration) Schedule and other federal procurement contracts.
Mount Type
Rack-mountable
Output voltage
120 V AC
Package Contents
- PDU3V6L2120LV 42-Outlets PDU
- Cable Retention Brackets With Installation Hardware
- Rack-mounting Hardware
- Owner's Manual
Plug/Connector Type
NEMA L21-20P
Product Name
PDU3V6L2120LV 42-Outlets PDU
Product Type
PDU
Protection Type
Overload Protection
Protection Type
Circuit Protection
Protection Type
Accidental Power Shutdown
Rack Height
0U
Receptacle Type
NEMA 5-15/20R
Weight (Approximate)
12.70 lb
Width
2.2"
