Tripp Lite PDU 3-Phase Basic 208-240V 8.6kW 36 C13 9 C19 16/20A 70in 0URM
Tripp Lite PDU 3-Phase Basic 208-240V 8.6kW 36 C13 9 C19 16/20A 70in 0URM - Basic - IEC 60309 16/20A RED (3P+N+E) - 36 x IEC 60320 C13, 9 x IEC 60320 C19 - 360 V AC, 380 V AC, 400 V AC, 415 V AC - 0U - Vertical/Toolless - Rack-mountable - TAA Compliant
| $429.60 | Retail $632.74 |
- Ideal no-frills PDU for telecom, security, audio/video and other network applications
- 36 C13 and 6 C19 single-phase outlets distribute AC power to connected equipment
- Switchless design helps prevent accidental shutdowns that can lead to costly downtime
- 6 ft. power cord with IEC 309 16/20A Red 3-phase input connects to AC source
- Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases
- 2-year limited warranty
By:
Tripp Lite
Manufacturer:
Tripp Lite by Eaton
Product ID:
99647
Item:
PDU3XV6G20
UPC Code:
037332255679
Our Part #
8JU667
Condition
New
$429.60EA
$632.74
$632.74
Availability
Only 37 Left In Stock
You may be also interested
Product description
Tripp Lite PDU 3-Phase Basic 208-240V 8.6kW 36 C13 9 C19 16/20A 70in 0URM - Basic - IEC 60309 16/20A RED (3P+N+E) - 36 x IEC 60320 C13, 9 x IEC 60320 C19 - 360 V AC, 380 V AC, 400 V AC, 415 V AC - 0U - Vertical/Toolless - Rack-mountable - TAA Compliant
Basic - IEC 60309 16/20A RED (3P+N+E) - 36 x IEC 60320 C13, 9 x IEC 60320 C19 - 360 V AC, 380 V AC, 400 V AC, 415 V AC - 0U - Vertical/Toolless - Rack-mountable - TAA Compliant
Specifications
Locking Receptacles
Cord Retention Bracket
Mounting Orientation
Vertical/Toolless
PDU Type
Basic
Phase
Three Phase
Power Rating (Watt)
11.50 kW
Receptacle Detail
9 x IEC 60320 C19
Receptacle Detail
36 x IEC 60320 C13
UPC Alternates
037332255679
Brand Name
Tripp Lite
Country of origin
Taiwan
Depth
1.9"
Environmental Certification
RoHS
Environmentally Friendly
Yes
Height
70"
Input current
16 A
Input Voltage Range
360 V AC - 415 V AC
Limited Warranty
2 Year
Manufacturer
Tripp Lite by Eaton
Manufacturer Part Number
PDU3XV6G20
Manufacturer Website Address
http://www.tripplite.com
Marketing Information
3-Phase 360-415V input / 208V-240V output PDU Distributes Network-Grade Power to Multiple Loads
This basic PDU is an ideal no-frills unit for networking telecom security audio/video and sound reinforcement applications. Recommended for small to mid-sized data centers computer rooms and network closets the PDU3XV6G20 features 36 C13 and six C19 (208-240V) outlets in three single-phase output load banks for connecting equipment. A six-foot (1.8-meter) cord with IEC 309 16/20A Red 360-415V (3P+N+E) 3-phase input plug connects to your facility's AC power source generator or protected UPS system to distribute power to connected loads.
Easy to Install Vertically in an EIA-Standard 19 in. Rack
The 70-inch 0U PDU's all-metal housing mounts vertically using the pre-installed toolless mounting buttons or the included brackets. Spare buttons are also included. Use the included PDUMVROTATEBRKT kit to install the PDU with outlets facing the rear for better airflow or equipment access. Cable retention brackets keep power cords organized and your rack free of clutter. The PDU's switchless design helps prevent an accidental shutdown which could lead to costly downtime.
TAA-Compliant for GSA Schedule Purchases
The PDU3XV6G20 is compliant with the Federal Trade Agreements Act (TAA) which makes it eligible for GSA (General Services Administration) Schedule and other federal procurement contracts.
Mount Type
Rack-mountable
Output voltage
240 V AC
Output voltage
208 V AC
Output voltage
230 V AC
Output voltage
220 V AC
Package Contents
- PDU3XV6G20 45-Outlets PDU
- Cable Retention Brackets With Installation Hardware
- Rack-mounting Hardware
- Owner's Manual
Plug/Connector Type
IEC 60309 16/20A Red (3P+N+E)
Product Name
PDU3XV6G20 45-Outlets PDU
Product Type
PDU
Protection Type
Accidental Power Shutdown
Rack Height
0U
Receptacle Type
IEC 60320 C13
Receptacle Type
IEC 60320 C19
Weight (Approximate)
9 lb
Width
2.2"
