Transition Networks M/E-ISW Transceiver/Media Converter
Transition Networks M/E-ISW Transceiver/Media Converter - 1 x Network (RJ-45) - 1 x SC Ports - DuplexSC Port - Multi-mode - Fast Ethernet - 10/100Base-TX, 100Base-FX - Rail-mountable, Wall Mountable
| $180.11 | Retail $230.00 |
- Unit and Port LEDs provide quick status
- Auto-Negotiation
- Fixed Full-Duplex on fiber
- Auto-MDI/MDIX
- Link Pass Through
- Active Link Pass Through on SFP version
- Automatic Link Restoration
- Far-End-Fault (FEF)
- DC and AC power inputs via terminal block
- Includes barrel connector pig-tail cable
By:
Transition Networks
Manufacturer:
Transition Networks, Inc
Product ID:
123876
Item:
M/E-ISW-FX-02(SC)
UPC Code:
648177042494
Our Part #
5TF280
Condition
New
$180.11EA
$230.00
$230.00
Availability
Only 9 Left In Stock
Product description
Transition Networks M/E-ISW Transceiver/Media Converter - 1 x Network (RJ-45) - 1 x SC Ports - DuplexSC Port - Multi-mode - Fast Ethernet - 10/100Base-TX, 100Base-FX - Rail-mountable, Wall Mountable
1 x Network (RJ-45) - 1 x SC Ports - DuplexSC Port - Multi-mode - Fast Ethernet - 10/100Base-TX, 100Base-FX - Rail-mountable, Wall Mountable
Specifications
Fiber Mode Supported
Multi-mode
Fiber Optic Wavelength
1310 nm
Maximum Distance Supported
1.24 Mile
SC Port Type
Duplex
UPC Alternates
648177042494 999554588105
Brand Name
Transition Networks
Country of origin
Taiwan
Depth
3.3"
Environmental Certification
RoHS
Environmental Certification
WEEE
Environmentally Friendly
Yes
Ethernet Technology
Fast Ethernet
Form factor
Wall Mountable
Form factor
Rail-mountable
Height
0.9"
Limited Warranty
Lifetime
Manufacturer
Transition Networks Inc
Manufacturer Part Number
M/E-ISW-FX-02(SC)
Manufacturer Website Address
http://www.transition.com
Marketing Information
The M/E-ISW Series is a hardened Fast Ethernet Mini media converter that provides a cost effective plug-and-play media conversion between 10/100Base-TX ports and 100Base-FX ports for hardened or outdoor 10/100 environments. With its supported operating temperature range of -40°C to 75°C the Mini offers a space saving alternative for converting copper to fiber in extreme environments.
Media Type Supported
Twisted Pair
Media Type Supported
Optical Fiber
Network Technology
100Base-FX
Network Technology
10/100Base-TX
Number of Network (RJ-45) Ports
1
Package Contents
- M/E-ISW Transceiver/Media Converter
- Barrel Connector Pig-tail Cable
- DIN Rail Clip and Velcro
Power source
Power Supply
Product Name
M/E-ISW Transceiver/Media Converter
Product Series
M/E-ISW
Product Type
Transceiver/Media Converter
Total Number of Ports
2
Weight (Approximate)
2 lb
Width
1.8"
