Axiom 100Mbs POE RJ45 to 100BASE-LX Fiber Media Converter - SMF, SC, 10km,1310nm
Axiom 100Mbs POE RJ45 to 100BASE-LX Fiber Media Converter - SMF, SC, 10km,1310nm - Network (RJ-45) - 1x PoE (RJ-45) Ports - 1 x SC Ports - Single-mode - Fast Ethernet - 100Base-LX
| $134.02 |
- Expand your network capacity and fulfill requirement with this 2 transceiver/media converter
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
- With 100Base-LX technology get up to 100Mbps data transfer rate over optical fiber cable
By:
Axiom
Manufacturer:
Axiom Memory Solutions
Product ID:
143811
Item:
MCP31-F1-S3S10-AX
UPC Code:
840177840258
Our Part #
43201553
Condition
New
$134.02EA
Availability
Only 1 Left In Stock
Product description
Axiom 100Mbs POE RJ45 to 100BASE-LX Fiber Media Converter - SMF, SC, 10km,1310nm - Network (RJ-45) - 1x PoE (RJ-45) Ports - 1 x SC Ports - Single-mode - Fast Ethernet - 100Base-LX
Network (RJ-45) - 1x PoE (RJ-45) Ports - 1 x SC Ports - Single-mode - Fast Ethernet - 100Base-LX
Specifications
Fiber Mode Supported
Single-mode
Fiber Optic Wavelength
1310 nm
Maximum Distance Supported
6.21 Mile
Network (RJ-45)
Yes
Number of PoE (RJ-45) Ports
1
PoE Port Type
PSE
UPC Alternates
840177840258
Brand Name
Axiom
Ethernet Technology
Fast Ethernet
Limited Warranty
1 Year
Manufacturer
Axiom Memory Solutions
Manufacturer Part Number
MCP31-F1-S3S10-AX
Manufacturer Website Address
http://www.axiommemory.com
Marketing Information
Features
The Axiom 100Mbps POE (PSE) Series are a 10/100Base-TX to 100Base-FX media converter which allows two types of network segment to be connected easily. Compliant with IEEE802.3af standard the AC/DC powered PoE media converter is a Power Sourcing Equipment (PSE) which combines data transferred over a fiber optic link with 48V (or other voltage) power supply providing power to IEEE802.3af powered device (PD) over CAT5e/CAT6 UTP cable (cable length up to 100meters / 330feet).
Features:
- 10/100Base-TX UTP to 100Base-FX fiber media conversion
- IEEE802.3af PoE PSE compatible
- Built-in AC/DC power supply
- Over-current protection
- DIP switch to set different configurations
- LFP (Link Fault Pass-through) support
Media Type Supported
Twisted Pair
Media Type Supported
Optical Fiber
Network Technology
100Base-LX
Power source
AC/DC
Product Name
100Mbs POE RJ45 to 100BASE-LX Fiber Media Converter - SMF SC 10km1310nm
Product Series
POE (PSE)
Product Type
Transceiver/Media Converter
Total Number of Ports
2
