Axiom 1Gbs POE RJ45 to 1000BASE-SX Fiber Media Converter - MMF, SC, 2km, 1310nm
Axiom 1Gbs POE RJ45 to 1000BASE-SX Fiber Media Converter - MMF, SC, 2km, 1310nm - Network (RJ-45) - 1x PoE (RJ-45) Ports - 1 x SC Ports - Multi-mode - Gigabit Ethernet - 1000Base-SX, 10/100/1000Base-T
| $134.02 |
- Expand your network capacity and fulfill requirement with this 2 transceiver/media converter
- Supports twisted pair cables for durability and improved signal transfer while ensuring smooth and seamless data transfer
- With 1000Base-SX technology get up to 1000Mbps data transfer rate over optical fiber cable
By:
Axiom
Manufacturer:
Axiom Memory Solutions
Product ID:
143846
Item:
MCP32-F1-M3S2-AX
UPC Code:
840177840128
Our Part #
43201553
Condition
New
$134.02EA
Availability
Only 1 Left In Stock
Product description
Axiom 1Gbs POE RJ45 to 1000BASE-SX Fiber Media Converter - MMF, SC, 2km, 1310nm - Network (RJ-45) - 1x PoE (RJ-45) Ports - 1 x SC Ports - Multi-mode - Gigabit Ethernet - 1000Base-SX, 10/100/1000Base-T
Network (RJ-45) - 1x PoE (RJ-45) Ports - 1 x SC Ports - Multi-mode - Gigabit Ethernet - 1000Base-SX, 10/100/1000Base-T
Specifications
Fiber Mode Supported
Multi-mode
Fiber Optic Wavelength
1310 nm
Maximum Distance Supported
1.24 Mile
Network (RJ-45)
Yes
Number of PoE (RJ-45) Ports
1
PoE Port Type
PSE
UPC Alternates
840177840128
Brand Name
Axiom
Ethernet Technology
Gigabit Ethernet
Limited Warranty
1 Year
Manufacturer
Axiom Memory Solutions
Manufacturer Part Number
MCP32-F1-M3S2-AX
Manufacturer Website Address
http://www.axiommemory.com
Marketing Information
Features
The Axiom POE (PSE) Series are a 10/100/1000Base-TX to 1000Base-FX (also can be forced to 100Base-FX) media converter which allows two types of network segment to be connected easily. Compliant with IEEE802.3af standard the AC/DC powered PoE media converter is a Power Sourcing Equipment (PSE) which combines data transferred over a fiber optic link with 48V (or other voltage) power supply providing power to or IEEE802.3af powered device (PD) over CAT5e/CAT6 UTP cable (cable length up to 100meters / 330feet).
Features:
- 10/100/1000Base-TX UTP to 1000Base-FX fiber media conversion
- IEEE802.3af PoE PSE compatible
- Built-in AC/DC power supply
- Over-current protection
- DIP switch to set different configurations
- LFP (Link Fault Pass-through) support
Media Type Supported
Twisted Pair
Media Type Supported
Optical Fiber
Network Technology
10/100/1000Base-T
Network Technology
1000Base-SX
Power source
AC/DC
Product Name
1Gbs POE RJ45 to 1000BASE-SX Fiber Media Converter - MMF SC 2km 1310nm
Product Series
POE (PSE)
Product Type
Transceiver/Media Converter
Total Number of Ports
2
