Gefen HDMI to 3GSDI Converter
Gefen HDMI to 3GSDI Converter - 225 MHz - 150 MHz to 225 MHz - 1 x HDMI In - USB
| $327.64 | Retail $402.00 |
- Convert signal from one form to another with this signal converter
- Supports up to 225 MHz frequency
- Features HDMI input to get connected with the top of the line HDMI supported devices
- Establishes a rapid connection with USB devices
By:
Gefen
Manufacturer:
Gefen, Inc
Product ID:
176200
Item:
EXT-HD-3G-C
UPC Code:
818252149053
Our Part #
39121008
Condition
New
$327.64EA
$402.00
$402.00
Availability
Only 4 Left In Stock
Product description
Gefen HDMI to 3GSDI Converter - 225 MHz - 150 MHz to 225 MHz - 1 x HDMI In - USB
225 MHz - 150 MHz to 225 MHz - 1 x HDMI In - USB
Specifications
UPC Alternates
818252149053 888814797275
Additional Information
- Converts HDMI to SDI
- Input resolutions up to 1920 x 1200 (WUXGA) and 1080p Full HD
- Output resolutions up to 1080p60
- Supports HDMI 12 bit color and SDI 10-bit color
- Supports Color Spaces: 4:4:4 (RGB and YCbCr) and 4:2:2 (YCbCr )
- Supports 3G-SDI Levels A and B
- Up to LPCM 7.1 audio support
- Field configurable via DIP switch settings or Gefen Syner-G™ software
- Gefen Syner-G™ simplifies in-field firmware updates and advanced EDID management
- Mini USB port for use with Gefen Syner-G™
- Wide power supply operating range (6V to 24V DC)
- Locking power supply connector
- 1/4-20 industry-standard camera gear attachment thread on bottom
- Surface-mountable using the included detachable bracket
Brand Name
Gefen
Depth
2.3"
Height
1.2"
Manufacturer
Gefen Inc
Manufacturer Part Number
EXT-HD-3G-C
Manufacturer Website Address
http://www.gefen.com
Marketing Information
Use an HDMI source with an SDI display or downstream equipment
The Gefen HD-3G-C converts audio and video from HDMI to 3G-SDI and single link HD-SDI. Resolutions up to 1080p Full HD and audio formats up to 8 channels of LPCM are supported. This product is fully compatible with the Gefen Syner-G™ software suite. The Gefen Syner-G™ is a powerful set of software tools specifically designed to help discover configure/customize manage monitor and upgrade Gefen products. The Gefen EXT-HD-3G-C's compact enclosure while light enough to be held in place using double sided Velcro® tape features an ISO standard 1/4-20 attachment provision as well as a detachable surface-mounting bracket. This along with a flexible power input circuitry capable of accepting a wide range of DC voltages and a locking power supply connector make the EXT-HD-3G-C ideal for cutting edge mobile A/V applications as well as high performance fixed installations.
Maximum Frequency
225 MHz
Minimum Frequency
150 MHz
Package Contents
- 1 x HDMI to 3GSDI Converter
- 1 x 6 ft. Locking HDMI Cable (CAB-HD-LCK-06MM)
- 1 x Surface Mounting Bracket
- 1 x 12V DC Power Supply (EXT-PS121.5AIP-3P)
- 1 x Quick-Start Guide (QSG-EXT-HD-3G-C)
Packaged Quantity
1
Product Name
HDMI to 3GSDI Converter
Product Type
Signal Converter
USB
Yes
Weight (Approximate)
5.29 oz
Width
2.9"
