CyberPower PDU30BT8F8R Single Phase 100 - 125 VAC 30A Basic PDU
CyberPower PDU30BT8F8R Single Phase 100 - 125 VAC 30A Basic PDU - 16 Outlets, 12 ft, NEMA L5-30P, Horizontal, 1U, Lifetime Warranty
| $238.96 | Retail $279.95 |
- Basic PDU
- 16 NEMA 5-20R output receptacles (8 Front/8 Rear)
- 120V AC - 50/60Hz - 30-amp electrical capacity with circuit breaker
- 1U Rack Mount - Rugged industrial-grade metal housing
By:
CyberPower
Manufacturer:
CyberPower Systems, Inc
Product ID:
65005
Item:
PDU30BT8F8R
UPC Code:
649532902125
Our Part #
9GM226
Condition
New
$238.96EA
$279.95
$279.95
Availability
Only 29 Left In Stock
Product description
CyberPower PDU30BT8F8R Single Phase 100 - 125 VAC 30A Basic PDU - 16 Outlets, 12 ft, NEMA L5-30P, Horizontal, 1U, Lifetime Warranty
16 Outlets, 12 ft, NEMA L5-30P, Horizontal, 1U, Lifetime Warranty
Specifications
Mounting Orientation
Vertical
PDU Type
Basic
Phase
Single Phase
Receptacle Detail
16 x NEMA 5-20R
UPC Alternates
649532902125
Brand Name
CyberPower
Certifications & Standards
- UL60950_1 certified by ETL
- CSA C22.2
Depth
2.3"
Energy Star
No
Environmental Certification
RoHS
Environmentally Friendly
Yes
Height
1.8"
Input voltage
120 V AC
Input Voltage Range
100 V AC - 125 V AC
Limited Warranty
Lifetime
Manufacturer
CyberPower Systems Inc
Manufacturer Part Number
PDU30BT8F8R
Manufacturer Website Address
http://www.cyberpowersystems.com
Marketing Information
The CyberPower PDU30BT8F8R a 16-outlet (8 front 8 rear) rackmount basic power distribution unit (PDU) provides 100 - 125 V 30A output. It distributes power to 16 NEMA 5-20R receptacles from a single NEMA L5-30P twist lock plug with unfiltered electrical pass-through. Designed for datacenters and other electrically demanding applications the PDU30BT8F8R has rugged industrial-grade metal housing and a 12-foot AC power cord. It can be mounted either horizontally or vertically includes a cord retention tray and is ETL/RoHS certified. A limited lifetime warranty covers defects in materials and workmanship in the product under normal use and conditions.
Power DistributionDelivers AC power to servers equipment and connected devices via a power distribution unit.
Switch-Free Design
Safeguards against accidental power shutdown.
Network-Grade Plugs and Outlets
Highly durable construction ensures the efficient distribution of power in demanding IT or industrial environments to servers equipment and connected devices.
Long Input Power Cord
Reaches distant power sources allowing the PDU to be placed where it's needed.
Twist Lock Plug
Secures an outlet by twisting and locking into place to prevent accidental disconnection.
Cord Retention Tray
Secures power cords keeping them organized and accessible. Helps cords stay plugged in.
Configurable Mounting Brackets
Allow for installation of the PDU in the following configurations: 0U (vertical under counter and wall mount) 1U (horizontal vertical under counter and wall mount) and 2U (horizontal and wall mount).
Durable Metal Housing
Protects internal components and resists damage from impact or abrasions within challenging industrial environments. Also extends the life of the product.
Limited Lifetime Warranty
Covers defects in materials and workmanship in the product under normal use and conditions. See warranty for details.
What's In The Box
PDU Cord Retention Tray User Manual Screw Kit Cord Clip Kit Horizontal Mounting Brackets Vertical Mounting Brackets Product Registration Card
Mount Type
Rack-mountable
Package Contents
- Basic PDU30BT8F8R 16-Outlets PDU
- Cord Retention Tray
- User Manual
- Screw Kit
- Cord Clip Kit
- Horizontal Mounting Brackets
- Vertical Mounting Brackets
- Product Registration Card
Plug/Connector Type
NEMA L5-30P
Product Name
Basic PDU30BT8F8R 16-Outlets PDU
Product Series
Basic PDU
Product Type
PDU
Protection Type
Overload Protection
Rack Height
1U
Receptacle Type
NEMA 5-20R
Weight (Approximate)
6 lb
Width
17.5"
