ATEN VGA Booster (1280 x 1024@70m)-TAA Compliant
ATEN VGA Booster (1280 x 1024@70m)-TAA Compliant - 1920 x 1200 - 300 MHzMaximum Video Bandwidth - 229.66 ft Maximum Operating Distance - VGA In - VGA Out - Metal
| $50.27 | Retail $75.00 |
- Long distance transmission - up to 70 m
- Adjustable video compensation - manually adjust signal strength to compensate for distance
- Superior video quality - up to 1920 x 1200 (30 m); 1280 x 1024 (70 m)
- Supports VGA, XGA, SVGA, UXGA, WUXGA, and multisync monitors
- Supports wide screen formats
- Supports hot-plugging
- Compact housing
- LED indication of power status and source device
- Plug-and-play - no software installation required
By:
ATEN
Manufacturer:
ATEN Technology, Inc
Product ID:
77174
Item:
VB100
UPC Code:
974573871209
Our Part #
ZM1011
Condition
New
$50.27EA
$75.00
$75.00
Availability
Only 2 Left In Stock
Product description
ATEN VGA Booster (1280 x 1024@70m)-TAA Compliant - 1920 x 1200 - 300 MHzMaximum Video Bandwidth - 229.66 ft Maximum Operating Distance - VGA In - VGA Out - Metal
1920 x 1200 - 300 MHzMaximum Video Bandwidth - 229.66 ft Maximum Operating Distance - VGA In - VGA Out - Metal
Specifications
Product Material
Metal
UPC Alternates
608631020918 672792004209 974573871209
Brand Name
ATEN
Environmental Certification
RoHS
Environmental Certification
WEEE
Environmentally Friendly
Yes
Height
0.8"
Input voltage
5 V DC
Length
1.4"
Manufacturer
ATEN Technology Inc
Manufacturer Part Number
VB100
Manufacturer Website Address
http://www.aten.com/us/en/
Marketing Information
The VB100 VGA Booster amplifies the VGA signal from a source device and transmits it to a display up to 70 meters away. The VGA booster extends the display distance without any signal loss; to bring you a crystal clear video display at a longer distance. The VB100 is built with a compact housing design for easy installation and manual gain control to improve image quality at different distances. The VB100 can be powered from the VGA source and has a built-in LED indicator for power. The VB100 supports hotplugging and requires no software forinstallation making it an easy compact and affordable solution to extend your VGA display.
Maximum Operating Distance
229.66 ft
Maximum Video Bandwidth
300 MHz
Maximum Video Resolution
1920 x 1200
Package Contents
- VGA Booster (1280 x 1024@70m)
- 1 x Power Adapter
- 1 x User Instructions
Packaged Quantity
1
Product Line
VanCryst
Product Name
VGA Booster (1280 x 1024@70m)
Product Type
Signal Repeater
Weight (Approximate)
2.12 oz
Width
2.7"
