Lantronix EMG 7500 - Edge Management Gateway
Lantronix EMG 7500 - Edge Management Gateway - Remote Management
| $998.65 | Retail $999.00 |
- Intelligent Centralized Management
- Always-on secure out-of-band access
- 4G/LTE cellular failover and failback
- Policy-based device and feature access
- Collect and store asset telemetry data
- Secure REST APIs to access data
- Automation with Python scripting
- Cisco IP SLA performance monitoring
- Data securely encrypted inflight and at rest
- Software-defined networking
By:
Lantronix
Manufacturer:
Lantronix, Inc
Product ID:
59979
Item:
EMG751001S
UPC Code:
783384243422
Our Part #
43222634
Condition
New
$998.65EA
$999.00
$999.00
Availability
Currently out of stock
You may be also interested
Product description
Lantronix EMG 7500 - Edge Management Gateway - Remote Management
Remote Management
Specifications
UPC Alternates
783384243422
Additional Information
- RS232 Serial 4-Port LTE Cellular
- Enterprise-grade security Secure Sockets Layer (TLS v1 v1.1 v1.2 v1.3)
- Packet filtering (firewall)
- Per port user permissions
- Configurable user/group rights
- Remote authentication: LDAP/ADRADIUS Kerberos TACACS+ NIS
- Local username/password
- NIST-certified implementation of AES (Advanced Encryption Standards) as specified by FIPS-197
- FIPS 140-2 compliant cryptography (Certificate #1878)
- Software programmable reversible pinouts on device ports Serial RS232
- Telnet/SSH to EMG command line interface
- Telnet/SSH/RAW-TCP direct to an IP address
- HTML5 support for Java-free web terminal SSH access to console ports
- Multiple Telnet/SSH sessions
- Simultaneous user access to the same console port
- Port buffering-256 KB per port
- Port logging to local files syslog USB thumb drive SD card and NFS share
- System audit and port logging
- Event notification via email SNMP or Syslog entry
- Character string recognition
- Quick setup and configuration web interface (TLS)
- CLI setup script
- CLI (Telnet SSH WebTerminal or direct console port access)
- SNMP (MIB II) -v1 v2 v3 compatible custom MIBs
- RPM (remote power management) feature to control and monitor industry leading PDU & UPS devices
- Active user list display port monitoring and timeout
- Diagnostics and port status counters
- Performance monitoring utility
- Packet generation utility
- Network trace utility
- Optional digital I/O and special integration with Sensorsoft environmental sensors
- Local subnet search for other Lantronix console manager solutions
- Maximum 15 users per device port
- DHCP and BOOTP for dynamic IP address assignment
- NTP for time synchronization
- FTP TFTP SFTP SCP client for file transfers
- DNS IP address name resolution
- SSH TLS SSL Telnet and TCP for connections in/out of every device port UDP PPP with PAP/CHAP NFS and CIFS for data storage
- StrongSwan IPsec VPN client
- RIP and RIPv2
- IPv6 Addressing supported
- Front Panel Console and Logging: 1 RJ45 Port Serial RS232 1 USB Port Host type A
- Front Panel Connectivity: 2 RJ45 Ports Ethernet (10/100/1000Mbps)
- Back Panel Logging: 1 microSD Slot
- Back Panel Connectivity: LTE/4G Cellular Radio with antennas and microSIM slot optional Wi-Fi and antennas
- Plug and go connectivity support for sensors and accessories used to measure/ detect temperature humidity power availability and dry-contact closures
- 1/2 GB Internal NAND Flash
- 1/2 GB Internal DRAM
- External Storage: microSD slot for up to 128 GB Flash
- Power Usage: 20W
- Compatible with the Lantronix ConsoleFlow™ central management software
- Temperature:
- Operating: 0 to 50° C (32 to 122° F) 30 to 90%RH non-condensing
- Storage: -20 to 80° C (-4 to 176° F) 10 to 90% relative humidity non-condensing
Application/Usage
Remote Management
Brand Name
Lantronix
Depth
6.4"
Height
1.7"
Limited Warranty
3 Year
Manufacturer
Lantronix Inc
Manufacturer Part Number
EMG751001S
Manufacturer Website Address
http://www.lantronix.com
Marketing Information
The Lantronix® EMG™ 7500 - Edge Management Gateway is the newest addition to the EMG family of edge solutions for branch offices remote locations retail stores where small port count fixed configurations and integrated cellular connectivity is needed at a cost-effective price.
Easy Centralized Management - ConsoleFlow™
ConsoleFlow™ is Lantronix's Software as a Service cloud or on-premise management platform for all deployed Lantronix edge management gateways and connected IT equipment. It offers a single pane of glass for centralized management and automated monitoring with real-time notifications. Mobile access from any iOS or Android platform provides secure access to your IT equipment. ConsoleFlow™
Cost-Effective Secure Connectivity - Anytime Anywhere
The EMG7500 boasts a smaller size than its EMG8500 sibling while still offering up to 8 management ports.
The EMG7500 is great for customers where space and cost are of primary concern. This edge management gateway is perfectly suited for branch offices and unmanned locations such as ATM's cell towers etc. This cost-effective member of the EMG family has fixed FRU's integrated cellular connectivity and internal flash memory. Connectivity Services
Quick Recovery from Downtimes
An integrated automatic fail-over/fail-back mechanism allows users to connect to their network equipment even when the primary network connection is congested or unresponsive. The EMG7500 can failover to a cellular 4G/LTE connection where all global carriers are supported with services such as Private APN VPN access public and private IP addressing. Network Performance Monitoring with support of IPSLA simulation traffic can ensure continuous and reliable network communication and help mitigate Lights Out scenarios.
Easy Centralized Management - ConsoleFlow™
ConsoleFlow™ is Lantronix's Software as a Service cloud or on-premise management platform for all deployed Lantronix edge management gateways and connected IT equipment. It offers a single pane of glass for centralized management and automated monitoring with real-time notifications. Mobile access from any iOS or Android platform provides secure access to your IT equipment. ConsoleFlow™
Cost-Effective Secure Connectivity - Anytime Anywhere
The EMG7500 boasts a smaller size than its EMG8500 sibling while still offering up to 8 management ports.
The EMG7500 is great for customers where space and cost are of primary concern. This edge management gateway is perfectly suited for branch offices and unmanned locations such as ATM's cell towers etc. This cost-effective member of the EMG family has fixed FRU's integrated cellular connectivity and internal flash memory. Connectivity Services
Quick Recovery from Downtimes
An integrated automatic fail-over/fail-back mechanism allows users to connect to their network equipment even when the primary network connection is congested or unresponsive. The EMG7500 can failover to a cellular 4G/LTE connection where all global carriers are supported with services such as Private APN VPN access public and private IP addressing. Network Performance Monitoring with support of IPSLA simulation traffic can ensure continuous and reliable network communication and help mitigate Lights Out scenarios.
Package Contents
- EMG 7500 - Edge Management Gateway
- Desktop Power Supply
Product Condition
New
Product Line
EMG
Product Model
7500
Product Name
EMG 7500 - Edge Management Gateway
Product Type
Infrastructure Management Equipment
Width
5.7"
