CyberPower Switched ATS PDU PDU24005 10-Outlets PDU
CyberPower Switched ATS PDU PDU24005 10-Outlets PDU - Metered - IEC 60320 C20 - 8 x IEC 60320 C13, 2 x IEC 60320 C19 - 230 V AC - 1U - Horizontal - Rack-mountable
| $2,208.95 |
- Amps: 20A (Derated to 16A)
- Volts: 200-240V
- Frequency: 50/60Hz
- Plug type: 2 x IEC-320 C20
- Outlets: 8 x IEC-320 C13, 2 x IEC-320 C19
- Size: 1U Rackmount
- Phase: Single
- Warranty: 3 year
By:
CyberPower
Manufacturer:
CyberPower Systems, Inc
Product ID:
65139
Item:
PDU24005
UPC Code:
649532933358
Our Part #
01FL39
Condition
New
$2,208.95EA
Availability
Currently out of stock
Product description
CyberPower Switched ATS PDU PDU24005 10-Outlets PDU - Metered - IEC 60320 C20 - 8 x IEC 60320 C13, 2 x IEC 60320 C19 - 230 V AC - 1U - Horizontal - Rack-mountable
Metered - IEC 60320 C20 - 8 x IEC 60320 C13, 2 x IEC 60320 C19 - 230 V AC - 1U - Horizontal - Rack-mountable
Specifications
Locking Receptacles
Cord Retention Tray
Mounting Orientation
Horizontal
PDU Type
Metered Auto Transfer Switch
PDU Type
Metered
Phase
Single Phase
Plug/Connector Detail
2 x IEC 60320 C20
Receptacle Detail
8 x IEC 60320 C13
Receptacle Detail
2 x IEC 60320 C19
UPC Alternates
649532933358
Additional Information
- Cord Length :10 ft (3.0 m)
- Derated Input Current :16 A
- Input Frequency Range :50 Hz - 60 Hz
- Input Overload Protection :20A x 2
- Phase :Single Phase
- Plug Style :Straight (Socket)
- Outlet Banks :1
- Overload Protection :None
- Power Source Transfer Time :2-7 ms
- Source Failure Detection Time :2-3 ms
- Total Transfer Time :<10 ms
- Hardware Connection Port :Serial (RJ45)
- LCD :Multifunction LCD
- LED Indicators :Source Status
- Upgradeable firmware :Yes
- Color :Black
- Cord Retention Tray/Cord Organizers :Yes
- External Site Ground Pin :Yes
- Form Factors Supported :1U Rackmount
- Material of Construction :Metal
- Style :Rackmount
- Operating Elevation :0 - 13123 ft (0 - 4000 m)
- Operating Relative Humidity :0 - 95 % (non-condensing)
- Operating Temperature :32 - 113 °F (0 - 45 °C)
- Storage Elevation :0 - 49213 ft (0 - 14999 m)
- Storage Temperature :5 - 131 °F (-15 - 55 °C)
- Safety :UL62368 :FCC Class A :cTUVus/CE/UKCA
Brand Name
CyberPower
Country of origin
China
Depth
8.5"
Design
Modular
Environmental Certification
RoHS
Environmentally Friendly
Yes
Form factor
Hot-swappable
Height
1.7"
Height
1.8"
Input current
16 A
Input current
20 A
Input voltage
230 V AC
Input Voltage Range
200 V AC - 240 V AC
Limited Warranty
3 Year
Limited Warranty
2 Year
Manufacturer
CyberPower Systems Inc
Manufacturer Part Number
PDU24005
Manufacturer Website Address
http://www.cyberpowersystems.com
Marketing Information
Ensure continued operation of critical devices with the CyberPower PDU24005 Metered ATS PDU. Ideal for data centers and network closets this unit provides power redundancy to single-corded connected equipment. If power for the primary source exceeds the lower or upper thresholds or if power fails the PDU will switch to the secondary power source to ensure continuous operation. The PDU will switch back to the primary power source when incoming power becomes stable.
The PDU24005 supports inputs between 200-240V and includes (8) IEC C13 and (2) IEC C19 outlets. Dual IEC C20 power cords are plugged into separate power sources (A and B) and information about each power source is provided via LED indicator lights on the front of the unit. Other features include an LCD with selectable background color ugradeable firmware and network-grade plugs and outlets. The CyberPower PDU24005 is protected by a three-year limited warranty.
Marketing Information
CyberPower PDU24005 provides output from a UPS unit generator or utility power to multiple connected devices in IT environments. Dual power cords can be plugged into separate power sources to provide redundancy to single-corded connected equipment. If the selected power source exceeds the desired thresholds or fails the ATS PDU will automatically switch to the other power source within 10 ms (Source Failure Detection Time: 2-3 ms. Power Source Transfer Time: 2-7 ms) to ensure continuous operation.
The unit comes with a hot-swappable multifunction readout that displays real-time vitals including current input voltage power consumption levels in amps and watts. The digital LCD display is also color configurable allowing easy maintenance and monitoring of the ATS PDU. Users can change LCD's colors to easily categorize devices between multiple machines in server room and IT environments. The firmware can also be conveniently upgraded via the USB port ensuring the latest features and updates are available for users.
The product can be connected to a PC through the serial port to perform local control of the ATS PDU.
Mount Type
Rack-mountable
Package Contents
- ATS PDU24005 10-Outlets PDU
- User's Manual
- Cord Retention Tray
- Mounting Brackets
- Cable Ties
- Screw Kit
- Power Cord
- Serial Cable
Plug/Connector Type
IEC 60320 C20
Product color
Black
Product Name
ATS PDU24005 10-Outlets PDU
Product Name
Switched ATS PDU PDU24005 10-Outlets PDU
Product Series
Switched ATS PDU
Product Series
ATS
Product Series
Metered ATS PDU
Product Type
PDU
Protection Type
Circuit Breaker
Protection Type
Overload Protection
Rack Height
1U
Receptacle Type
IEC 60320 C19
Receptacle Type
IEC 60320 C13
Weight (Approximate)
7.05 lb
Weight (Approximate)
7.61 lb
Width
17"
Width
17.1"
