Tripp Lite PDU 3-Phase Metered 208V 14.4kW 36 C13; 6 C19; 3 L6-30R 0URM

Tripp Lite PDU 3-Phase Metered 208V 14.4kW 36 C13; 6 C19; 3 L6-30R 0URM - 6 x IEC 60320 C19, 36 x IEC 60320 C13, 3 x NEMA L6-30R - 14.40 kVA - Vertical Rackmount"
$583.69Retail $1,499.48
  • Metered 14.4kW 3 Phase 208V PDU; 70 in. / 178cm 0U vertical rackmount
  • Reports load current per-phase via set of 3 built-in current meters
  • Hubbell CS8365C 50A (3P+E) 208V 3 phase input; 6 ft. / 1.8m line cord
  • 45 208V outlets total (36 C13, 6 C19, 3 L6-30R)
  • Toolless button-mount installation; cord retention brackets included
  • Federal Trade Agreements Act / TAA Compliant for GSA Schedule purchases
By:
Tripp Lite
Manufacturer:
Tripp Lite by Eaton
Product ID:
83729
Item:
PDU3MV6H50A
UPC Code:
037332163882
Our Part #
PK7844
Condition
New
$583.69EA
$1,499.48
Availability Only 50 Left In Stock
Great Deals Everyday

You may be also interested

Product description

Tripp Lite PDU 3-Phase Metered 208V 14.4kW 36 C13; 6 C19; 3 L6-30R 0URM - 6 x IEC 60320 C19, 36 x IEC 60320 C13, 3 x NEMA L6-30R - 14.40 kVA - Vertical Rackmount"
6 x IEC 60320 C19, 36 x IEC 60320 C13, 3 x NEMA L6-30R - 14.40 kVA - Vertical Rackmount"

Specifications

Mounting Orientation
Vertical
Power Rating (Watt)
14.40 kW
Receptacle Detail
3 x NEMA L6-30R
Receptacle Detail
36 x IEC 60320 C13
Receptacle Detail
6 x IEC 60320 C19
UPC Alternates
037332163882 742712005538
Brand Name
Tripp Lite
Country of origin
Taiwan
Depth
2.2"
Environmental Certification
RoHS
Environmentally Friendly
Yes
Height
70"
Input voltage
230 V AC
Limited Warranty
2 Year
Manufacturer
Tripp Lite by Eaton
Manufacturer Part Number
PDU3MV6H50A
Manufacturer Website Address
http://www.tripplite.com
Marketing Information

Tripp Lite 3 phase Metered PDU / Power Distribution Units offer real-time local reporting of current levels in amps via set of 3 built-in digital meters. Enables visual monitoring of PDU current levels to preserve proper loading balance and prevent circuit overloads as additional equipment is added. Offers reliable rackmount multi-outlet power distribution from any protected UPS generator or mains input power source. High quality design includes rugged all-metal housing and secure rackmount installation with included mounting accessories.

Mount Type
Rack-mountable
Output voltage
208 V AC
Package Contents
  • Metered PDU3MV6H50A 45-Outlets PDU
  • Cord Retention Brackets
  • Rack Mounting Brackets
  • Owner's Manual
Plug/Connector Type
Hubbell CS8365C
Product Name
Metered PDU3MV6H50A 45-Outlets PDU
Product Series
Metered
Product Type
PDU
Protection Type
Overload Protection
Receptacle Type
IEC 60320 C19
Receptacle Type
NEMA L6-30R
Receptacle Type
IEC 60320 C13
Weight (Approximate)
14.50 lb
Width
2.7"
